Front wing F-ONE EAGLE X UHM CARBON
Next item >

Front wing F-ONE GRAVITY FCT 1800
637.95
DO YOU NEED ADVICE

DOWNWIND / WINGFOIL

F-ONE EAGLE is a front foil wing designed for speed-oriented riding and efficient downwind performance, delivering extended flight time, low drag and a wide operating range. Its thin profile and High Modulus Carbon construction ensure efficiency and stability in both wingfoiling and SUP foiling.

Read more

 Product videos
ShortText:

Speed and glide focused design

The EAGLE is designed as a high-efficiency wing, allowing long flight times without sudden speed loss. Its very thin profile and upturned winglets reduce induced drag, resulting in stable glide across a wide speed range.

Stable flight and wide operating range

The wing generates smooth, consistent lift and remains predictable as speeds vary. This makes it comfortable to ride both slowly and fast, without abrupt stalls.

Wingfoiling performance

In wingfoiling, the EAGLE delivers strong upwind ability, stability and constant cruising speed. Pumping is efficient and precise, while maneuvers remain easy to control in changing conditions.

Downwind character

The wing efficiently captures water energy, enabling long, smooth downwind runs. It is well suited for riders seeking speed and glide without stepping into extreme race-oriented designs.

Construction and stiffness

Built with a full monobloc structure using pre-preg technology and High Modulus Carbon, the EAGLE offers excellent stiffness and load transmission. The Titan connection allows compatibility with aluminum or carbon masts.

Size guide

  • 690 / 790 cm² – fast and dynamic sizes for powered wingfoiling, long downwinds and lighter advanced riders
  • 890 / 990 cm² – the most versatile options for advanced riders combining speed and glide
  • 1090 / 1190 / 1290 cm² – increased accessibility and stability, ideal for SUP downwind entry and heavier riders; 1290 cm² excels in light wind and flat downwind conditions

Features

  • High Modulus Carbon - Carbon fiber layup 1.5x stiffer than standard constructions, delivering stability, precision and efficiency
  • Thin Optimized Profile - Very thin profile reducing drag and extending the usable speed range
  • Monobloc Front Wing - One-piece front wing and fuselage construction eliminating unwanted movement
  • Titan Connection - Very stiff and direct connection between foil components, compact and hydrodynamically efficient
  • Pre Preg Technology - Pre-impregnated carbon fibers ensure low weight, high strength and consistent quality

Set includes

  • Front wing
  • Cover
  • Screws: 3x M6-32mm + 2x M6-25mm
  • Torx



For instant answer - open the chat and ask your question. We're active 9.00-17.00 CET.

Is it afterhours? ​No problem - leave us a message and we’ll respond early the next day.

​+48 513 020 570

For those who prefer phone calls - that's our number. You can give us a ring between 9.00-17.00 CET.

Specification
VariantFront wing F-ONE EAGLE HM CARBON 690Front wing F-ONE EAGLE HM CARBON 790Front wing F-ONE EAGLE HM CARBON 890Front wing F-ONE EAGLE HM CARBON 990Front wing F-ONE EAGLE HM CARBON 1090Front wing F-ONE EAGLE HM CARBON 1290Front wing F-ONE EAGLE HM CARBON 1190
Modular systemF-ONE TITANF-ONE TITANF-ONE TITANF-ONE TITANF-ONE TITANF-ONE TITANF-ONE TITAN
Front wing area (cm²)690790890990109012901190
Front wing span (cm)82879397102111106
Front wing aspect ratio9.79.59.69.59.59.59.4
Wing materialCarbonCarbonCarbonCarbonCarbonCarbonCarbon
DisciplineFreeride, Freerace, DownwindFreeride, Freerace, DownwindFreeride, Freerace, DownwindFreeride, Freerace, DownwindFreeride, Freerace, DownwindFreeride, Freerace, DownwindFreeride, Freerace, Downwind
Screw set3x M6-32mm + 2x M6-25mm3x M6-32mm + 2x M6-25mm3x M6-32mm + 2x M6-25mm3x M6-32mm + 2x M6-25mm3x M6-32mm + 2x M6-25mm3x M6-32mm + 2x M6-25mm3x M6-32mm + 2x M6-25mm
Foilbag includedYesYesYesYesYesYesYes
Weight (kg)0.921.11.231.311.481.581.55
SKUFONE-77227-0130-0690FONE-77227-0131-0790FONE-77227-0132-0890FONE-77227-0133-0990FONE-77227-0134-1090FONE-77227-0135-1290FONE-77227-0136-1190
